OPTICAL VIEWFINDER
EXACTLY YOUR SHOT
Shooting with the optical viewfinder is fast, thanks to minimal shutter lag and 45-point all cross-type Optical Viewfinder AF* with phase-detection. It lets you see exactly what the lens sees in virtually every lighting condition, and allows you to hold the camera close to your body for extra stability. Focus points, exposure and other helpful info is overlaid onto the image.
Real-time Capture
with Minimal Shutter Lag
OPTICAL VIEWFINDER AUTOFOCUS
FOCUS NEARLY ANYWHERE
Thanks to the EOS Rebel T7i camera’s 45-point all cross-type Optical Viewfinder AF* with phase-detection, you’ll be ready to take the shot when the moment happens. Focusing happens so fast, there's minimal lag time between when you press the shutter button and when the photo is taken.
45-point All Cross-type AF*
AUTOFOCUS ACROSS THE WHOLE FRAME
Compose the photo you want without having to worry about the autofocus, thanks to the EOS Rebel T7i camera’s 45-point all cross-type AF* that covers a wide area across the frame. Use the optical viewfinder to line up your shot, and the 45 AF points* will lock on your subject whether it’s in the center of the image or artistically off to the side.
1 / 6
Large Zone AF Mode: Camera focuses on the object that falls within the selected group of AF points.
2 / 6
Large Zone AF Mode: Camera focuses on the object that falls within the selected group of AF points.
3 / 6
Zone AF Mode: Camera focuses on the object that falls within the selected preset zone.
4 / 6
Zone AF Mode: Camera focuses on the object that falls within the selected preset zone.
5 / 6
Automatic Selection AF (Default Mode): Camera automatically picks what to focus on.
6 / 6
Automatic Selection AF (Default Mode): Camera automatically picks what to focus on.
Color Detection AF
LOCK ON FACES
Capture the faces of your friends and family with ease. Color Detection AF can detect skin tones in the image, focusing on them and setting the exposure automatically. This can help make sure you never miss that special smile or expression.
With Color Detection AFWithout Color Detection AF
6.0 fps Continuous Shooting
CAPTURE THE ACTION
With fast autofocus and fast processing, the EOS Rebel T7i camera can capture up to 6.0 frames per second so you can get the exact moment you want, even with a fast-moving subject like the family pet or an athlete during a game.
* The number of AF points, cross-type AF points and Dual cross-type AF points vary depending on the lens used.
LCD AUTOFOCUS
GET THE WORLD IN FOCUS
Using 24.2 million phase difference sensors, the EOS Rebel T7i camera’s Dual Pixel CMOS AF is the world’s fastest AF at 0.03 sec.** with quick, smooth and accurate autofocus when shooting both stills and video in Live View mode. Take photos faster, without having to re-frame or move the camera. Track subjects in videos with effortless precision.
The World’s
Fastest
Autofocusing Speed of 0.03 sec.
Focus Over a Wide AF Area
Signal from photodiode A
Signal from photodiode B
Each of the 24.2 million phase difference sensors has two separate photodiodes (A and B).
Focused
** Among all the interchangeable lens digital cameras incorporating the APS-C size image sensors with phase-difference detection AF on the image plane. As of February 14, 2017 (based on Canon research). Calculated based on the resulting AF speed measured according to the CIPA guidelines. (Varies depending on the shooting conditions and the lenses used.) Internal measurement method.
[Measurement conditions]
Focusing brightness: EV 12 (room temperature, ISO 100)
Shooting mode: M
Lens used: EF-S 18–55mm f/4–5.6 IS STM (at focal length of 55mm)
Live View AF shooting using the shutter button.
AF method: Live 1-point AF (with Center AF point)
AF operation: One-Shot AF
Servo AF
KEEP LOCKED ON THE ACTION
Servo AF constantly tracks moving subjects, working in conjunction with the Dual Pixel CMOS AF to keep them in sharp focus, even during high-speed continuous shooting. Capture in sharp detail the goalie blocking the shot or the runner crossing the finish line.
Touch AF
EASY SELECTIVE FOCUS
For the artistic photo or dramatic video you want, sometimes a creative use of focus is required. With Touch AF, simply tap the area of the image you want the camera to focus on most and watch it come in clean and clear.
Works with EF Lenses
TECHNOLOGY FOR ALL LENS OPTIONS
From telephoto to wide angle, to macro, prime and whatever type of lens your creativity requires, Canon’s EF and EF-S lenses are compatible with the EOS Rebel T7i camera, providing an array of options.
Over
60
EF & EF-S Lenses
